Online Total Iron Analyzer KTI600 is water quality monitoring equipment. Which is used to monitor the total content of Iron in water.

Contact Company

Xi'an Kacise Optronics Tech Co., Ltd.

Shaanxi, China

(699) Views

(10) Contacts

Principle of Total Iron Analyzer
Iron and its compounds are low toxicity and micro-toxicity, high iron content of water often with yellow, iron smell, on the appearance of water have an impact. The main sources of iron pollution in water are mineral processing, smelting, iron smelting, mechanical processing, industrial electroplating, acid washing wastewater and so on.
Principle: iron in water sample is digested into iron ions by digestion solution, the high-valent iron ion is converted into ferrous ion by adding reductant, and stable orange-red complex is formed between the ferrous ion and o-phenanthroline in acid medium, the iron content in the water sample can be calculated.

                                                            Model
                                                            KTI600

                                                            Monitoring Parameter
                                                            TFe

                                                            Contour Dimension
                                                            505 * 395 * 671(length * width * height unit mm)

                                                            Method
                                                            O-Phenanthroline spectrophotometric method

                                                            Range
                                                            (0.02-1) mg/L and (0.02-10) mg/L were expandable

                                                            Display unit
                                                            12232 dot matrix display, 7-inch LCD touch screen dual display

                                                            Power Requirements
                                                            Rated voltage (220 ± 22) VAC frequency (50 ± 1) % Hz

                                                            Measurement mode
                                                            Manual  measurement,     continuous    measurement,            periodic measurement,      fixed-point     measurement       and automatic calibration measurement Sample check

                                                            Ambient Humidity
                                                            (65 ± 20) % Rh

                                                            Measurement period
                                                            Anywhere from 30 minutes to 24 hours

                                                            Zero Drift
                                                            ≤ ± 5% F. S

                                                            Range Drift
                                                            ≤ ± 5% F. S

                                                            Repeatability
                                                            ≤5%

                                                            Ambient Temperature
                                                            (5-35) C

                                                            Indication error
                                                            ≤ ± 5%

                                                            MBTF
                                                            > 720 hours

                                                            Stored data
                                                            Five years of data storage

                                                            Communication interface
                                                            2 Route 4-20mA,1 Route RS232,1 Route RS485

Monitoring of enterprise rainwater and sewage
Monitoring of total phosphorus in the municipal pipe network, pumping stations, groundwater, river water, lake water, and seawater.
