The online sludge concentration sensor adopts the principle of 135 ° backlight, an 880nm infrared LED light source, and adopts a unique adaptive software algorithm to effectively remove the interference of external light. Fiber optic structure with excellent repeatability and stability. The automatic cleaning brush can eliminate air bubbles and reduce the impact of contamination on the measurement, making the maintenance cycle longer and maintaining excellent stability for long-term online use.

Technical Parameters

product name	The self-cleaning sludge concentration sensor
model	DSS450	DSS451
principle	135 ° backlight
Range	3 ～ 9999mg / L or 0 ～ 50g / L
Resolution	0.1mg / L or 0.1g / L
Accuracy	<3%
temperature range	0~ 50°C
Protection class	Ip68
Sensor interface	Support RS-485, MODBUS protocol
assembly	Input
Power information	DC 5 ~ 12V, current <50mA (when not cleaning)
Probe cable length	10 meters (default), can be customized
Housing material	SS316
Optical window	optical fiber
Self-cleaning system	Have

1. Digital sensor, RS-485 output, support MODBUS
2. With automatic cleaning brush to prevent staining and eliminate air bubbles
3. Compensate the color of water quality to eliminate the interference of color on the measurement
4. using fiber-optic structure, not affected by ambient light

ADVANTAGE:

The Sludge Concentration Sensor is a fiber structure with excellent repeatability and stability.

With the automatic cleaning brush, it can eliminate air bubbles, reduce the impact of pollution on measurement, extend the maintenance cycle, and maintain excellent stability for long-term online use.
