Online Calcium Ion Sensor

(0 reviews)

645 USD

(271) Views

(0) Contacts

$645.00/ piece

Contact Company

Yantai Chemins Instrument Co., Ltd.

Shandong, China

(2156) Views

(20) Contacts

Description
Product Reviews

The online calcium sensor is manufactured using a PVC film-based calcium selective electrode to measure calcium content in water, with temperature compensation to ensure that the test is fast, simple, accurate, and economical.  Easy to connect to PLC, DCS, industrial control computer, universal controller, paperless recording instrument or touch screen, and other third-party equipment.
Patented calcium ion electrodes, the internal reference fluid exudes from the microporous salt bridge extremely slowly at a pressure of at least 100KPa (1Bar). Such a reference system is very stable and has a longer electrode life than ordinary industrial electrodes.
Easy installation: 3/4 "NPT thread (pipe thread) for easy sink mounting or mounting on pipes and tanks.
The online Calcium ion sensor
Online calcium ion sensor is made of a calcium ion selective electrode based on PVC film, which is used to test the calcium ion content in water, with temperature compensation, to ensure that the test is fast, simple, accurate, and economical. This user manual introduces the technical parameters, maintenance, and communication protocol of calcium ion sensors in detail.
1、Output: RS-485 bus, Modbus/RTU protocol, which is convenient to connect to third-party equipment such as PLC, DCS, industrial control computer, general controller, paperless recording instrument, or touch screen.
2、Patented calcium ion electrode, the internal reference solution seeps out of the microporous salt bridge very slowly under the pressure of at least 100KPa(1Bar). This reference system is very stable, and its electrode life is longer than that of ordinary industrial electrodes.
3、Easy to install: 3/4 inch NPT thread (pipe thread), which is convenient for submerged installation or installation in pipelines and tanks.
4、IP68 protection level.
