TD63 750 Membrane PP Tube Diffuser

Featured

TD63 750 Membrane PP Tube Diffuser

(0 reviews)

Get Price

(2784) Views

(0) Contacts

1 - 99 sets
$10.00
100 - 999 sets
$9.80
>= 1000 sets
$9.00

Contact Company

Hangzhou Juntai Plastic Products Co., Ltd

Hangzhou, China

(3984) Views

(91) Contacts

TD63 750 mm membrane tube diffusers are the best solution for long and narrow aeration tanks. The opportunity to choose different materials, connection threads, and sizes make the TD63 750 mm membrane tube diffuser fit any type of wastewater. The diffusers in Juntai are produced with the latest technology and the diffusers are used in wastewater treatment plants. The projection of each diffuser of Juntai was done after Research and Development studies that responded to the requests of wastewater treatment plants. Materials used in Juntai diffusers are carefully selected according to the processes of wastewater treatment plants and tested regularly before shipment.
The wastewater treatment of activated sludge and contact aeration process and aquarium will all need a high Oxygen transfer rate or Oxygen transfer efficiency, OTE., and low-pressure loss by the membrane. The reinforced EPDM can continuously create fine bubbles from slots on the EPDM membrane of disc-type or tube-type diffuser. The expected duty life may be over 5 years without tearing or bursting. There are other material selections of self-sink silicon rubber membranes, ceramic diffusers, air stone, and coil-looking diffusers. There is also a course bubble air diffuser for the application of the liquid mixture. The diffuser can be used for a roots blower, ring blower, and linear air pump. The diffuser also has the advantage of much energy reduction.

                                                            Service area:(m²)
                                                            0.75-2.5

                                                            Flow range（m³/h）
                                                            2-14

                                                            Bubble size(mm)
                                                            1-2

                                                            Moc
                                                            Special formula EPDM

                                                            Connector
                                                            3/4NPT

                                                            Tube
                                                            reinforced ABS(Acrylonitrile Butadiene Styrene)with UV Protector

                                                            Length
                                                            750mm and other length

                                                            Diameter
                                                            63mm

1、Municipal wastewater treatment.

2、Industrial wastewater treatment.

3、Clean water treatment.

4、Sludge stabilization.

5、Wastewater ozone diffusion.

6、Aeration of fish ponds.

7、Aeration of streams and lakes.

Juntai Smart Tube Diffuser Advantage
1、TD63 1000 mm Membrane aeration tube diffuser can be installed to stainless steel box profiles by stainless steel long nipples.
2、Connections are 3/4". Also, male options are available.
3、Material of the pipe is reinforced ABS(Acrylonitrile Butadiene Styrene) and UV protector for UV rays and different chemical processes.
4、Standard material of diffuser membranes is EPDM.
5、Juntai aeration tube diffuser capacity of the Diffusers are some 2 times higher than that of conventional air diffusers, which allows for decreasing significantly capital costs of aeration projects with Juntai Air Diffusers
6、It warrants between 35%-45% oxygen efficiency.
7、It holds energy costs very low because of minimum pressure loss.
8、The capital costs of aeration projects are significantly lower compared to conventional membrane diffusers systems
