500LPH JuJinRO Industrial Reverse Osmosis System Water Filter KJ-RO-1T

Contact Company

Guangxi JuJin Environmental Protection Technology Co.,Ltd

Guangxi, China

(621) Views

(3) Contacts

Overview of the Product
The device has a touch screen and PLC, is simple to use, and can be remotely monitored (requires a network cable, hotspot, and WiFi password conditions). It also periodically reminds users to update the filter.
A PLC program is used to set up the electrical control system, and a 10-inch touch screen display on the operation panel allows real-time system operation status display.
Provide a consistent supply of clean water
The system runs completely on its own without human involvement.
Concurrently, the touch screen may be operated and controlled, and Internet of Things connectivity can be used to do remote monitoring and control. module Reverse osmosis pumps for osmosis filtering RO system tank.
Schematic Diagram
The specific treatment process of the reverse osmosis water treatment system is as follows: reverse osmosis water treatment system→ pure water tank→ sterilization filter→ UV sterilizer→ variable frequency water supply pump→ water point whole house reverse osmosis; raw water tank→ raw water pump (booster pump→), quartz sand filter→ activated carbon filter→ precision filter→ centrifugal pump;
The whole system runs fully automatically, without manual intervention;
In order to guarantee a steady supply of pure water, the electrical control system has a PLC program. The operation panel is shown on a 10-inch touch screen, which can be used to control and monitor the system in real time. It can also be used to implement remote monitoring and control via the Internet of Things communication module.

                                                            Brand Name
                                                            JuJinRO

                                                            Working Process
                                                            Raw water pump--Quatz sand Filter--Activated carbon Filter--Fine Filter--High pressure pump---RO purifier.

                                                            Water Production Capacity
                                                            ≥500LPH commercial ro unit.

                                                            Voltage
                                                            AC220V/380V-50Hz osmosis water system.

                                                            Inlet Water Pressure
                                                            0.2-0.3Mpa.

                                                            InLet Water Temperature
                                                            5-35℃

                                                            Panel
                                                            PLC Touch screen or Regular panle optional reverse osmosis system price.

                                                            Material
                                                            Fiberglass or SS304, SS316 Stainless steel customized

                                                            Control Valve
                                                            Manual or Full automatic customized

                                                            Processing Capacity
                                                            500 LPH

                                                            Power
                                                            2.14kW

                                                            Material
                                                            Stainless steel or Fiberglass optional

                                                            Control Program
                                                            Full automatic PLC

                                                            Equipment Dimensions
                                                            1500x650x1650mm

                                                            Tank Dimensions
                                                            250*1400mm

                                                            RO Membrane Materail
                                                            TFC

                                                            RO Membrane
                                                            ULP31-4040

                                                            Pressure
                                                            0.6Mpa
