Sewage Pump

Featured

Sewage Pump

(0 reviews)

Get Price

(3133) Views

(0) Contacts

1 - 19 pieces
$275.00
20 - 49 pieces
$222.00
>= 50 pieces
$200.00

Contact Company

Hangzhou Juntai Plastic Products Co., Ltd

Hangzhou, China

(3995) Views

(91) Contacts

JUNTAI SEWAGE PUMP
A sewage pump is a pump used to remove water that accumulates in a catch basin, commonly found in the basement of a home for secondary treatment of sewage If the basement is below the water table, water may enter the basin through the perimeter drains of the basement waterproofing system, or may flow in due to rain or natural groundwater. submersible sewage pumps are used in areas where basement flooding frequently occurs and to address moisture problems where the water table is above the foundation of the home's primary wastewater treatment
SEWAGE PUMP INSTLLATIONLLTION INSTRUCTIONS
1. Check whether pump fasteners are loosened and whether the pump body runner is blocked by foreign matters before installation to avoid damage to the impeller and pump body in running wastewater sludge.
2. Supporters for the outlet pipe should be installed separately so that the weight will not be added to the pump to prevent it from deformation. The pump base for both movable and fixed installation must be leveled by a level. After the base is ready, install the pump on the base and then use a level to check the horizontal and vertical situation between the pump and motor shaft. Use the iron shim to change the height of the base if the pump is out of level. Then grout the base and anchor bolt holes by pouring the concrete into the grout hole, reducing wastewater treatment costs.
3. Sewage treatment stages have levelness of the coupling device should be calibrated by a level when coupling installation is adopted. Horizontal level tolerance should not exceed 0.1mm/m. Use the measuring gauge to calibrate parallelism of two coupling rods to ensure the parallelism tolerance will not exceed 0.2mm/m.
4. Tighten the anchor bolt to make sure there is no looseness between the anchor bolt and concrete in case of a bad influence on the sewage air pump performance when starting.
5. For easy maintenance and safe use, install a regulating valve on the outlet pipe and a pressure gauge near the outlet to guarantee normal operation within the rated performance range, which lengthens the lifetime of sewage treatment plant air pumps.
6. Rotate the impeller from the suction side after installation. Disassemble the pump and find out the reasons there is friction or a stuck pump.
7. The processes of the wastewater treatment plant in pump installation can be divided into three types, movable type, fixed type, and coupling type

                                                            Warranty
                                                            3 years, one year

                                                            Weight
                                                            32KG

                                                            Customized support
                                                            OEM

                                                            Size
                                                            60*25*30CM

                                                            Brand Name
                                                            JUNTAI

                                                            Model Number
                                                            JT-QW

                                                            Place of Origin
                                                            Anhui, China

                                                            Certification
                                                            RoHS,ce,IECEE

                                                            Outlet Size
                                                            Custom

                                                            Voltage
                                                            220V/380V

                                                            Power Source
                                                            Electric

                                                            Cable Length
                                                            8M

                                                            Pressure
                                                            High Pressure

SEWAGE PUMP APPLICATION
Wide range of applications and powerful features:
1. Agricultural irrigation
2. River discharge
3. Engineering Discharge
4. Sewer drainage
5. Septic tank discharge
6. Basement drainage

SEWAGE PUMP ADVANTAGES
1. WQ/QW submersible pump sewage is developed with international advanced technology. It has been widely used in industrial, mining, construction, hospital, municipal engineering, garden, fountain, sewage treatment, chemical, define effluent, tertiary sewage treatment, anaerobic wastewater treatment, and other industries for more than ten years
2. The sewage pump submersible overcurrent parts are all made of sanes steel precision casting, which has the characteristics of no pollution and corrosion resistance and expands the application fields of water supply, aerobic wastewater treatment, and drainage
3. The sewage water pump is made of excellent stainless steel 304/316 material. It has a pure texture and beautiful appearance, which reduces secondary pollution and fully meets the requirements of national green environmental protection for primary sewage treatment
4. The drainage sewage pump is efficient, reasonable in structure, non-blocking, and ani-winding, and has the characteristics of safe and reliable operation and long service life. The dual-rail automatic coupling device is equipped as needed to facilitate the installation of tertiary treatment of sewage
5. The mechanical seal adopts double-end sealing material, uses high-quality hardly such as tungsten carbide, and runs in the oil chamber for a long time, which Can make the stainless steel sewage water pump run continuously for more than 10,000 hours for secondary sewage treatment
