Automatic Bottle Water Filling Machines

(0 reviews)

8000 USD

(265) Views

(0) Contacts

Automatic 3 In 1 Capping Washing Filling Mineral Water Drinking Plant 500Ml Bottle Water Filling Machines

$8,000.00 - $20,000.00/ 1 set/sets

Contact Company

Guangzhou Kaiyuan Water Treatment Equipment Co., Ltd.

Guangdong, China

(2176) Views

(17) Contacts

1)This machine is mainly used to fill the water. 2)Washing, filling, and capping are available in one machine. 3)The structure of conveying is hanging type and clamping the bottleneck to easily change bottle type. 4)The filling method adopts the isobaric filling so that the filling speed is faster and more stable. 5)Using the advanced PLC(Programmable Logic Controller) technology. 6)The major electrical apparatus are all products of well-known brands 7)The material tank is 304 stainless steel, with no sanitary dead Angle, in line with GMP standards. 8)Filling valve material: SUS304

                                                            Weight:
                                                            350kg

                                                            Keywords:
                                                            filling machines

                                                            Dimension(L*W*H):
                                                            1200L*950W*1950H

                                                            Key Selling Points:
                                                            High-accuracy

                                                            Warranty:
                                                            1 Year

                                                            Warranty of core components:
                                                            1 Year

                                                            Core Components:
                                                            Pump, Other, PLC, All Parts

                                                            Filling heads:
                                                            18

                                                            Washing heads:
                                                            18

                                                            Capping heads:
                                                            6

                                                            Material:
                                                            SUS-304(Food Grade)

                                                            Height of bottle:
                                                            140-320mm

                                                            Diameter of bottle:
                                                            50-95mm

                                                            Volume of bottle:
                                                            240-1500ml

                                                            Control:
                                                            PLC+ Touch Screen

                                                            Nominated Speed:
                                                            6000BPH 500ml

                                                            Filling Accuracy:
                                                            0.05%F.S.

                                                            Filling Material:
                                                            Water, Juice

                                                            Machinery Capacity:
                                                            4000BPH, 8000BPH, 12000BPH, 6000BPH, 20000BPH, 2000BPH, 1000BPH, 3000BPH
