Single Phase Hybrid Off Grid Solar Storage Inverter Growatt 500Vdc SPF 6000ES Plus 6KW

(0 reviews)

Get Price

(62) Views

(0) Contacts

Contact Company

Lovsun Solar Energy Co., Ltd

Hong Kong, China

(169) Views

(0) Contacts

                                                            Datasheet
                                                            SPF6000ESPlus

                                                            Battery Voltage
                                                            48VDC

                                                            Battery Type
                                                            Lithium/Lead-acid Inverter

                                                            Storage Temperature
                                                            – 15°C – 60°C

                                                            Altitude
                                                            <2000m

                                                            Operating Temperature
                                                            0°C – 55°C

                                                            Rated Power
                                                            6000VA/6000W

                                                            Parallel Capability
                                                            Yes, 6 units maximum

                                                            Humidity
                                                            5% to 95% Relative Humidity(Non-condensing)

                                                            AC Voltage Regulation (Battery Mode)
                                                            230VAC ± 5% @ 50/60Hz

                                                            Net Weight (kgs) Operating Environment
                                                            13.5

                                                            Surge Power
                                                            12000VA

                                                            Efficiency (Peak)
                                                            93%

                                                            Dimension (W/H/D)
                                                            460/395/132mm

                                                            Waveform
                                                            Pure sine wave

                                                            Transfer Time
                                                            10ms typical ，20ms Max

                                                            Frequency Range Physical Protection Degree
                                                            50Hz/60Hz (Auto sensing) IP20

                                                            Maximum PV Array Power
                                                            8000W

                                                            MPPT Range @ Operating Voltage
                                                            120VDC ~ 450VDC

                                                            Number of Independent MPP Trackers/ Strings Per MPP Tracker
                                                            2/1

                                                            Selectable Voltage Range
                                                            170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances)

                                                            Max. input current per MPP tracker
                                                            16A

                                                            Maximum PV Array Open Circuit Voltage
                                                            500VDC

                                                            Maximum Solar Charge Current AC Charger
                                                            100A

                                                            AC Input Voltage
                                                            230VAC

                                                            Charge Current
                                                            80A
