Small Power Battery N18650CH

(0 reviews)

Get Price

(230) Views

(0) Contacts

Contact Company

BAK Power Battery

Guangdong, China

(1172) Views

(3) Contacts

                                                            Cell material type
                                                            High Nickel

                                                            Single cell mass (KG)
                                                            <0.046

                                                            Internal resistance of single cell (mΩ)
                                                            ≤30

                                                            Maximum charging rate of battery
                                                            1C

                                                            Maximum discharge rate of battery cell
                                                            3C

                                                            Nominal voltage of single cell (V)
                                                            3.6

                                                            Dimensions of single cell (mm)
                                                            Height: 64.85 ± 0.25 Diameter:18.40±0.15

                                                            Typical capacity of single cell (Ah)
                                                            (0.2C) 2.6

                                                            Cell cycle life (100% DOD 25°C)
                                                            1000 circles>80%(RT0.5C/1C)

                                                            Battery cell charging and discharging temperature range (battery cell surface)
                                                            Charging: 0~55℃ Discharge: -20~70℃
