All In One 3KW Integrated Solar Energy System

(0 reviews)

(1080) Views

(0) Contacts

JSDSOLAR JHP-3000 3KW all-in-one solar system has a built-in inverter & MPPT charge controller & Lithium battery, and input and output sockets, cooling fans, input, and output protection are integrated into a box with handles, and four wheels.

$1,200.00 - $1,600.00/1 set/sets

Contact Company

Shenzhen Jinsdon Lighting Technology Co., Ltd.

messages.no address inserted..

(2432) Views

(5) Contacts

                                                            Brand Name
                                                            JSDSOLAR JHP-3000

                                                            Main parts
                                                            Solar Inverter ,  Solar MPPT Controller , Lifepo4 Battery

                                                            Acquired certifications
                                                            UL,PSE, FCC, CE, UN38.3,MSDS ,ROHS

                                                            Recommended PV
                                                            1200W

                                                            Products model
                                                            JHP3000

                                                            Built-in battery
                                                            3072WH

                                                            PV voltage
                                                            170~280VDC

                                                            Dimension LxWxH (mm)
                                                            450x195x620/450x195x620/585x240x700

                                                            Input voltage
                                                            110/120/220/230VAC

                                                            Output voltage
                                                            110/120/220/230VAC

                                                            Output frequency
                                                            50/60Hz

                                                            Output waveform
                                                            Pure sine wave

                                                            Output voltage
                                                            12V DC, 5V USB DC, 220V AC

                                                            DC Output port
                                                            DC Output port USB outputs *2 , 12VDC outputs*2

Features of Solar Energy System

Integrated Solar Energy System has a colourful display interface.
Integrated Solar Energy System has a touch setting screen.
Integrated Solar Energy System has one design to solve complicated cable connection process.
Integrated Solar Energy System has portable handlebars and easy mobility wheels design.
Integrated Solar Energy System has a charger, discharge, circuit short/open, etc, protection.
Integrated Solar Energy System has a high-frequency solar inverter.
Integrated Solar Energy System has MPPT solar charge controller.
Integrated Solar Energy System has 6000cycles LiFePO4 batteries.
Integrated Solar Energy System has a double cooling fan to expand the lifespan.
