PVDF series pressurized UF membrane modules use imported Arkema PVDF raw material, filtering precision is 0.1 micron, ultrafiltrate turbidity ≤1NTU. Outside-in the structure is applicable for raw water with high turbidity and SS. The external surface area of outside-in membranes is large and feasible to air washing or air-water backwashing, which greatly increases the anti-fouling ability of membrane modules. TMP of PVDF outside-in membrane modules are low, which greatly reduces energy consumption.

                                                            Membrane Material & ID / OD
                                                            PVDF（0.8/1.3mm）

                                                            Filter Type
                                                            Outside-in

                                                            Pore Size
                                                            0.1μm

                                                            Membrane Area, m2
                                                            47

                                                            Size, mm
                                                            Ø200x1710

                                                            Connector Size, mm
                                                            Ø50

                                                            Shell Material
                                                            UPVC

                                                            Sealing Material
                                                            Epoxy Resin+PU

                                                            SDI15 / Ultrafiltrate SDI15 2
                                                            ≤1NTU

                                                            Ultrafiltrate Turbidity
                                                            ≤3

                                                            Operating Flux
                                                            40~100L/m .h .

                                                            Backwashing Flux
                                                            100~150L/m .h

                                                            Ultrafiltrate Turbidity
                                                            ≤25NTU

                                                            Temperature
                                                            5~45℃

                                                            PH
                                                            5~9 (Washing2~12)

                                                            TMP
                                                            ≤0.15MPa

                                                            Backwashing Pressure
                                                            ≤0.15MPa

                                                            Backwashing Frequency
                                                            30~60min

                                                            CEB
                                                            1~4 (Times/day)

                                                            CIP
                                                            When it comes to Maximum TMP

                                                            Operating Pressure
                                                            ≤0.2MPa

Applications of PVDF Hollow Fiber Ultrafiltration Membrane

Treatment of surface water & groundwater
Municipal drinking water treatment
Reuse of industrial wastewater
RO
RO pretreatment

Features of PVDF Hollow Fiber Ultrafiltration Membrane

SS≤1mg/L、≤1NTU、SDI≤3.
Ultrafiltrate SS≤1mg/L, turbidity≤1NTU, SDI≤3.
Use imported PVDF raw material, which has good chemical resistance, good hydrophilicity, anti-aging ability, and long service life.
PVDF's 30% Strength is 30% higher than other NIPS PVDF in the market.
3~5 years service life under normal use.
