Residential Electric Water Heaters

(0 reviews)

Get Price

(151) Views

(0) Contacts

Contact Company

EQPT

Riyadh, Saudi Arabia

(417) Views

(1) Contacts

The specification of Electric Water Heater

Dynaclean™ is a PEX cross-linked polymer dip tube designed to minimize hot water mixing with incoming cold water and reduce silt accumulation.
Heat traps are factory-installed on connections at the intake and outlet to increase energy efficiency.
T&P Relief Valve: Side-mounted, factory-installed T&P safety relief valve (standard)
Some variants have the option of being top-mounted.
Drain Valve: Sturdy, impervious brass drain valve
The code conformity:

Complies with the Federal Energy Efficiency Standards (NAECA 2004).
Satisfies the standby loss standards set by the US DOE
Fulfills ASHRAE/IES 90.1 requirements

                                                            Warranty
                                                            6-year limited tank and parts warranty

                                                            Tank Construction Material
                                                            Heavy duty carbon steel

                                                            Maximum Working Pressure
                                                            150 psi (10 bar)

                                                            Test Pressure
                                                            300 psi (20 bar)

                                                            Inner Liner
                                                            Permaglas® glass coating for corrosion protection

                                                            Surface mounted thermostats with adjustable range
                                                            43°C (110°F) to 71°C (160°F)

                                                            Hi-limit safety control with factory set limit
                                                            at 83°C (180°F)

                                                            Accuracy
                                                            ±2.5°C (5°F)

                                                            Standard
                                                            Immersion type, zinc coated copper, 4.5 kW, 240V

                                                            Optional elements available (depending on model)
                                                            1.5 kW to 6.0 kW

                                                            Water Connections Standard
                                                            3/4″ inlet and outlet on all models

                                                            Anode Rod Coregard™
                                                            Aluminum anode with stainless steel core for extended corrosion protection

                                                            Residential models Certifications
                                                            UL 174 certified

                                                            Export models Certifications
                                                            UL 174, SASO, GSO, PAI, and IEC 60335-2-21 compliant

Important characteristics of electric water heaters:

Tall, short, and lowboy models are available to make room for different installation areas.
Dynaclean™ Diffuser Dip Tube: Reduces sediment buildup and maximizes efficiency by minimizing hot water interacting with cold water.
Compared to conventional steel anodes, the Coregard™ Anode Rod offers corrosion protection that lasts longer.
Permaglas® Glass Coating: Increases tank life and prevents corrosion in the steel tank.
Heat Traps: Reduce heat loss to increase energy efficiency.
Depending on the type, multiple element options enable heating capacity to be customized to meet particular needs.
The ability to adjust the water temperature is provided by adjustable thermostats.
Long-lasting Brass Drain Valve: Guarantees simple draining for upkeep or repairs.
T&P Relief Valve: Offers protection by automatically releasing pressure when it becomes too hot.
Respects Current Safety and Efficiency Standards: ensures both safe use and energy-efficient operation.
Long-Term Warranty: Offers reassurance with a limited warranty on parts and the tank for six years.
