FilterClear® High Rate Multi-Media Filtration

(0 reviews)

Get Price

(1382) Views

(0) Contacts

Contact Company

Bluewater Bio

London, United Kingdom

(2049) Views

(4) Contacts

FilterClear is a pressure multimedia filter technology that can effectively remove suspended particles from a variety of fluids, even at high loading velocities. Currently, more than 100 locations have FilterClear systems built, which treat water types such as seawater at desalination facilities, cooling waters at industrial sites, and secondary effluent at wastewater treatment plants.

The range of throughput is 5 m3/hr to 5000 m3/hr. Pharmaceuticals, food and drink, cooling water, RO pre-treatment for a variety of industries, distilleries, and public buildings like apartments, offices, hotels, and hospitals are examples of commercial applications. Other multimedia filters, continuous filters, deep bed filters, disc filters, and micro screens are also reasonably priced alternatives to FilterClear technology. It can take the place of ultrafiltration membranes upstream of RO membranes and has a solid track record in traditional filtration applications.

Multi-Media Filtration Principal Applications

Reverse osmosis desalination pretreatment.
Filtration of tertiary sewage for compliance or reuse.
Reuse, wastewater, cooling, and industrial processes.
drinkable water from a borehole or the surface.
treatment of greywater and rainwater.
Dosing and phosphorus elimination together.

Main Benefits of Multi-Media Filtration:

Exceptional performance thanks to ten years of specifically designed and applied proprietary stratified FilterClear® material with up to four layers.
High rate of loading (25–50 m³/m²/h, or 2–5 times the flow rate of rival systems).
High retention of solids (long backwash interval and low pressure drop).
Single-step, high-quality filtrate (SDI <3, NTU <0.1, BOD content <6 mg/l).
Low CAPEX (fewer vessels, 2–5 times less media).
Low OPEX (low electricity use, no chemical use).
Small backwash tanks, low backwash volume (less than 6% of filtrate), improved yield, and reduced waste.
Little footprint (smaller plant, 2–5 times smaller filter area).
Low O&M (easy to maintain, dependable, and straightforward).
Each vessel can use modular systems up to 1200 m2/h.
