Electric Sanitary Wafer Butterfly Valve

(0 reviews)

Get Price

(121) Views

(0) Contacts

Contact Company

Shanghai Yawang Valve Co., Ltd.

Shanghai, China

(732) Views

(4) Contacts

Product description of stainless steel electric butterfly valve:

1. The valve adopts a double eccentric structure, which has the sealing function of tighter and tighter, and the sealing performance is reliable.

2. The sealing material is made of stainless steel and nitrile oil-resistant rubber, which has a long service life.

3. The rubber sealing ring can be located on the valve body or on the butterfly plate and can be applied to media with different characteristics for users to choose from.

4. The butterfly plate adopts a frame structure, which has high strength, a large flow area, and small flow resistance.

5. The overall paint can effectively prevent corrosion and can be used for different media as long as the sealing material of the sealing valve seat is replaced.

6. The valve has a two-way sealing function. It is not controlled by the flow direction of the medium during installation, nor is it affected by the spatial position. It can be installed in any direction.

7. The valve has a unique structure, flexible operation, labor-saving, and convenience.

                                                            Nominal through DN (mm)
                                                            Wafer type 50-300 Flange 50～2000

                                                            Nominal pharmacological PN (MPa)
                                                            0.6                     1.0                1.6

                                                            Sealing test (MPa)
                                                            0.66                   1.1              1.76

                                                            Strength test (MPa)
                                                            0.9                    1.5                  2.4

                                                            proper temperature Nitrile rubber
                                                            -40℃～90℃

                                                            Fluorine rubber
                                                            -20℃～200℃

                                                            Leak rate
                                                            Comply with GB/T13927-92 standard

                                                            Drive mode
                                                            Worm gear drive, electric, pneumatic, hydraulic

                                                            Nominal diameter
                                                            DN50-200mm

                                                            link method
                                                            Butt welding

                                                            Body Material
                                                            Stainless steel (P4, P6)

                                                            sealing material
                                                            PTFE (F), fully lined with tetrafluoroethylene (F46)

                                                            Cylinder options
                                                            AT series

                                                            Cylinder form
                                                            Double acting, single acting (spring return)

                                                            ambient temperature
                                                            Standard type: -20~80℃

                                                            medium temperature
                                                            W1: -40~180℃, W5: -20~80℃, W7: -40~160℃

                                                            control method
                                                            Two-position cut-off (switch type), adjustment type, three-stage type (opening optional)

                                                            Nominal pressure
                                                            6, 10, 16bar (If you need higher pressure, please specify your requirements.)

                                                            Air pressure
                                                            Double acting: 4-8bar, single acting: 5-8bar
