Carbonated Water Production Machine

(0 reviews)

Get Price

(483) Views

(0) Contacts

>= 1 pieces
$54,000.00

Contact Company

Zhangjiagang JST Machinery Co., Ltd.

Jiangsu, China

(1576) Views

(4) Contacts

DCGF series isobaric filling machine is a three-in-one filling machine integrating washing, filling, and capping.
On the basis of introducing, digesting, and absorbing the foreign advanced technology, the equipment is innovated and developed according to the filling process requirements of aerated beverages. It is mainly used for cola, sparkling wine, and soda water.
The machine is reasonable in structure, safe and reliable, and easy to maintain.
It is ideal equipment for beverage filling plants.

                                                            Packaging Type
                                                            Barrel, Bottles, CANS, carbonated water production machine

                                                            Cap size
                                                            28mm as usual

                                                            Certification
                                                            CE,ISO

                                                            Packaging Material
                                                            Glass, Metal, Plastic, carbonated water production machine

                                                            Cap
                                                            Screw type

                                                            Type
                                                            Filling Machine

                                                            Warranty of core components
                                                            2 years

                                                            Warranty
                                                            2 years

                                                            Automatic Grade
                                                            Automatic

                                                            Driven Type
                                                            Electric

                                                            Control
                                                            PLC+touch screen

                                                            Voltage
                                                            380v,can be made to order

                                                            Place of Origin
                                                            Jiangsu, China

                                                            Machine material
                                                            SUS304

                                                            Brand Name
                                                            JST

                                                            Filling heads
                                                            18

                                                            Capping heads
                                                            6

                                                            Dimension(L*W*H)
                                                            4000X1900X2300mm

                                                            Weight
                                                            4500 KG

                                                            Machinery Capacity
                                                            4000BPH, 12000BPH

                                                            Washing heads
                                                            18

                                                            Filling Material
                                                            carbonated water drink

                                                            Core Components
                                                            Motor, Pressure vessel, Engine

                                                            Label material
                                                            PVC

Beverage
Food
Machinery & Hardware
Carbonated Water Production Machine

1. Compact structure, beautiful appearance, convenient operation, high automation, and low labor intensity. 2. Bottle transmission adopts bottle neck clamping technology. When changing the bottle quantity, it is not necessary to adjust the height of the equipment. It is only necessary to replace the guide plate and thumbwheel related to the bottle diameter and bottle mouth. 3. The parts in direct contact with the products are made of SUS 316L stainless steel, without process corner bags 4. The valve opening device is driven by the air cylinder; Open the valve timely according to the signal, and the action is accurate and reliable. 5. High speed, large capacity, high-precision filling valve, filling fast, accurate, no liquid loss. 6. The deflection control valve is used to continuously control the flow of fluid and material so that the hydraulic cylinder can maintain a small liquid level fluctuation and ensure filling accuracy. 7. Equipped with the CIP circuit and control program, the equipment is cleaned in place. 8. The capping head adopts a constant magnetic torque device to ensure the sealing quality without damaging the bottle cap. 9. The bottle cap classification system is used efficiently, and the perfect bottle cap lacks a protection device. 10. The bottle discharge thumbwheel adopts a downward spiral mode, and it is unnecessary to adjust the conveying height when changing the bottle quantity. 11. It has a perfect overload protection device, which can effectively protect the safety of equipment and operators. 12. Human-machine dialogue can be realized by using touch screen operation, and the operation status of the equipment is clear at a glance. 13. The main electrical components (touch screen, PLC, frequency converter, etc.) are imported famous brand products, such as Omron, Mitsubishi, Schneider, etc. 14. Pneumatic system components shall be famous brand products, SMC, FESTO, etc.
