FRP RO Membrane Housing

(0 reviews)

(200) Views

(0) Contacts

4" FRP RO membrane housing is the preferred choice for water treatment in the membrane process. 150 PSI to 1200 PSI, side port or end port.

Contact Company

Hebei ChengDa Water Technology Co., Ltd.

Hebei, China

(806) Views

(20) Contacts

Winder® series FRP membrane housings are applicable to multiple standard membrane elements, E.g. Filmtec, Hydranautics, Osmonics, Koch, Toray, CSM, Vontron and BDX, etc. And non-standard products could be tailor-made to meet the demand for your special projects.100% quality assurance test with 1.1 times of working pressure maintained for at least five minutes, we could guarantee safety and no leakage. Not sampling test.

Specification of 4" End Entry

Model No.	Design Pressure (PSI)	Operating Temperature	Connection	Element Length
W40E300	300	-10 °C – 49 °C	End port	40" × (1–4)
W40E450	450	-10 °C – 49 °C	End port	40" × (1–4)
W40E600	600	-10 °C – 49 °C	End port	40" × (1–4)
W40E1000	1000	-10 °C – 49 °C	End port	40" × (1–4)
W40E1200	1200	-10 °C – 49 °C	End port	40" × (1–4)

Specification of 4" Side Entry

Model No.	Design Pressure (PSI)	Operating Temperature	Connection	Element Length
W40S300	300	-10 °C – 49 °C	Side port	40" × (1–4)
W40S450	450	-10 °C – 49 °C	Side port	40" × (1–4)
W40S600	600	-10 °C – 49 °C	Side port	40" × (1–4)
W40S1000	1000	-10 °C – 49 °C	Side port	40" × (1–4)
W40S1200	1200	-10 °C – 49 °C	Side port	40" × (1–4)

                                                            Quality Assurance
                                                            Burst test with 6 times of its design pressure; 100000 times cycle test.

                                                            Warranty
                                                            Two years warranty for housing body against industry defects. One year warranty for spare parts.

                                                            Model
                                                            4"
