Water Softener Filter System Automatic and Manual De-Iron Ion Exchange Demineralizer Softening Remove The Hardness Descaling

(0 reviews)

Get Price

(798) Views

(0) Contacts

Contact Company

Guangzhou Ticktock Water Environmental Technology Co.,Ltd

Guangdong, China

(1781) Views

(0) Contacts

The method by which a water softener converts hard water into soft water is referred to as its working principle. Hard water is defined as having a high concentration of metal ions, like magnesium and calcium. These ions will cause scale to build in the water, which will lower the water's quality and shorten equipment lifespan. In order to make the water soft—which is good for both equipment maintenance and human health—the water softener's goal is to eliminate or minimize these metal ions. Currently, ion exchange and nanocrystal methods are the two most often utilized operating principles for water softening systems. The following provides an overview of the tenets and traits of these two approaches.
Ion exchange technique
Through the application of a unique resin, the ion exchange process lowers the hardness of water by absorbing metal ions like calcium and magnesium. The resin is covered in a lot of sodium ions, which are removed from the water when hard water flows through the resin and exchanges with metal ions like magnesium and calcium. As a result, the water that emerges has less metal ions and becomes soft.
The benefit of the ion exchange process is its ability to efficiently remove metal ions such as calcium, magnesium, and others from the water, resulting in an effluent with a hardness below the national limit of 0.03 mmol/L (i.e., 1/2Ca2+, 1/2Mg2+). The ion exchange process can also enhance the effluent's quality by removing certain organic materials like iron and manganese as well as some heavy metals.
The ion exchange method's drawback is that it requires periodic regeneration with brine to replenish the resin's adsorption capacity. The regeneration process creates waste brine and uses water and salt, both of which have an effect on the environment. Furthermore, the ion exchange process is unable to enhance the taste or color of the water or get rid of germs, viruses, or other pathogens.

                                                            Municipal tap water/underground/river water Soft water standard
                                                            calcium(Ca2+) and magnesium(Mg2+)<0.03mmol/L

                                                            Inlet water pressure
                                                            1-4 kg (when inlet water pressure is too low or no pressure

                                                            System voltage
                                                            220V(AC Reserved 2-hole socket)

                                                            Need toarrange pressure pump) Cleaning mode
                                                            Manual / Automatic

                                                            Inlet and outlet waterSpecification
                                                            D20-D63 external wire interface

                                                            Drainage specification
                                                            D20-D32 hose

                                                            Water supply
                                                            running continuous water supply, cleaning water off

                                                            Regenerating agent
                                                            soft water salt or sea salt

                                                            Regeneration time
                                                            20-90 minutes

                                                            Capacity
                                                            1.5-100 tons per hour

                                                            Filter material replacement cycle
                                                            3-5 years to replace once

                                                            Salt tank specification
                                                            25-1000L

                                                            Tank size
                                                            according to the model

                                                            Filtration principle
                                                            hard water→ion exchange →removal Calcium and magnesiumions→ soft water – water point

Water Softener Filter System Applications

A lot of systems, including air conditioners, evaporative condensers, exchangers, direct combustion engines, steam boilers, hot water boilers, and air conditioners, can benefit from the softening of supply water provided by ticktock water softener filters. In addition, it may be applied to hotels, softened water treatment in sectors including food and beverage, brewing, laundry, printing and dyeing, chemical, and pharmaceutical, as well as domestic water treatment in restaurants, office buildings, flats, homes, and so on.
