PERFORMANCE SPECIFICATIONS
Model	FM-600	FM-800
PV Input (DC)
PV Max Input Power(W)	350*2	210~500W
PV Max Input Voltage(V)	60	60
Start-up Voltage (V)	16	20
MPPT Voltage Range(V)	30~55	30~55
Max Input Current (A)	14*2	18*2
Number of MPPT Trackers	2	2
AC Output
Rated Output Power (W)	600	800
Nominal Output Current (A)	2.6	3.47
Power Factor	>0.99	>0.99
Max Parallel	8pcs	6pcs
Anti-islanding Protection	Yes	Yes
AC Short Circuit Protection	Yes	Yes
System
Max. Efficiency	96.70%	96.70%
Protection Class	CLASS I	CLASS I
Protection Level	IP67	IP67
Cooling Method	Natural Cooling	Natural Cooling
Monitoring	WIFI	WIFI
Operating Temperature Range (℃)	-30~+60	-30~+60
Manufacturer’s Warranty	10 Years	10 Years
Mechanical Data
Dimensions (W x Hx D mm)	22522537	22522537
Weight (kg)	2.7	3.6

                                                            Nominal Grid Voltage (V)
                                                            230(single-phase)

                                                            Grid Voltage Range (V)
                                                            180~264VAC

                                                            Max Total Harmonic Distortion
                                                            <3% (rated power)

                                                            Nominal Grid Frequency (Hz)
                                                            50Hz/60Hz
